| Output Power | 60KW | 80KW | 120KW | 160KW | 180KW | 240KW |
|---|---|---|---|---|---|---|
| Model | YLC-DC-60 | YLC-DC-80 | YLC-DC-120 | YLC-DC-160 | YLC-DC-180 | YLC-DC-240 |
| Output Current | 200A | 266A | 400A | 532A | 600A | 798A |
| Breaker | 160A | 200A | 250A | 400A | 400A | 500A |
| Output Voltage | 200-1000V | |||||
| Dimension (MM) | 1800*700*500 | |||||
| Screen Size | 10 Inches | |||||
| Installation Mode | Floor Installation | |||||
| Cooling Mode | Forced Air Cooling | |||||
| MTBF | 100000 hours | |||||
| Protection Level | IP55 | |||||
| Communication Interface | 4G / Wired Network | |||||
| Input Voltage | Three Phase 380V input AC | |||||
| Input Frequency | 45-65Hz | |||||
| Power Factor | 0.99 (above 50% load) | |||||
| Harmonic | THD:5% (above 50% load) | |||||
| Steady Flow Accuracy | <±1% | |||||
| Stable Voltage Accuracy | ±0.5% | |||||
| Operating Temperature | -35℃~+50℃ | |||||
| Storage Temperature | -40℃~+70℃ | |||||
| Altitude | ≤2000m | |||||
| Relative Humidity | 5%RH ~95%RH | |||||
| Noise Control | ≤65 dB@25°C | |||||
| Gun Length | 5 Meter | |||||
| International Protocol | EN IEC 61851-1, EN 61851-22, EN 62752 | |||||
| Auxiliary Power Source | 12-24V | |||||
| Security Features | Input overvoltage protection, undervoltage protection, output overvoltage protection, constant power overload protection, short circuit protection, grounding protection, overtemperature protection, lightning protection, emergency stop protection, leakage protection, insulation detection, door opening protection, battery reverse connection protection, relay sticking protection, etc. | |||||
