| Output Power | 60KW | 80KW | 120KW | 160KW | 180KW | 240KW |
|---|---|---|---|---|---|---|
| Model | YLC-DC-60 | YLC-DC-80 | YLC-DC-120 | YLC-DC-160 | YLC-DC-180 | YLC-DC-240 |
| Output Current of Each Gun | 200A | 266A | 400A | 532A | 600A | 798A |
| Breaker | 125A | 160A | 250A | 320A | 400A | 500A |
| Output Voltage | 200-1000V | |||||
| Dimension (MM) | 816*380*1600 | 720*450*1600 | ||||
| Screen Size | 7 Inches | |||||
| Installation Mode | Floor Installation | |||||
| Cooling Mode | Forced Air Cooling | |||||
| MTBF | 100000 hours | |||||
| Protection Level | IP55 | |||||
| Communication Interface | WIFI (Optional), Ethernet, 4G, OCPP 1.6 Json (OCPP 2.0 optional) | |||||
| Input Voltage | 400VAC±20% | |||||
| Input Frequency | 50/60Hz | |||||
| Power Factor | ≥0.99 @ 50%~100% loading | |||||
| Harmonic | ≤5% @ 50%~100% loading | |||||
| Steady Flow Accuracy | <±1% | |||||
| Stable Voltage Accuracy | ±0.5% | |||||
| Operating Temperature | -30℃ to +55℃ | |||||
| Storage Temperature | -40℃~+70℃ | |||||
| Altitude | ≤2000m | |||||
| Relative Humidity | 5%RH ~95%RH | |||||
| Noise Control | ≤65 dB@25°C | |||||
| Gun Length | 5 Meter | |||||
| International Protocol | EN IEC 61851-1, EN 61851-22, EN 62752 | |||||
| Auxiliary Power Source | 12Vdc | |||||
| Security Features | Over current protection, Residual current protection, Short circuit protection, floor protection, Surge protection, Over/Under voltage protection, Over/Under frequency protection, Over/Under temperature protection | |||||
