1 Dimension: —
2 Charging Port: Single Charging Gun
3 Installation Ways: Wall-Mounted / Column
4 Product Model: CS-DC-40 / CS-DC-30
5 Input Voltage: 3-Phases AC 380V
6 Output Current of Single Charging Port: 0-125A
7 Output Voltage: 200-1000V
| Power | 30KW / 40KW |
|---|---|
| User interface | 7-inch LCD color display touch screen |
| Charging guns | Single gun GB/T / CCS2 / CCS1 |
| Installation method | Wall-mounted / Column |
| Cable length | 5m |
| Working temperature | -40 ℃~+70℃ |
| Working humidity | 5%~95% without frost |
| Working altitude | <3000m |
| Protection level | IP55 |
| Cooling method | Forced air cooling |
| Noise control | 60dB |
| MTBF | 100000 hours |
| Input frequency | 45-65Hz |
| Input voltage | 380V Three phase |
| Output voltage | 200-1000V (constant power) |
| Single gun output current | 0-125A |
| Measurement accuracy | 0.5 level |
| Current limiting protection value | >110% |
| Stable voltage accuracy | ± 0.5% |
| Stable current accuracy | <±1% |
| Ripple coefficient | ± 0.5% |
| Efficiency | 94.5% |
| Power factor | 0.99 (above 50% load) |
| Harmonic content THD | 5% (above 50% load) |
| Charging mode | Automatic full charge / fixed battery / fixed amount / fixed time |
| Start up model | RFID Card, Scan code, VIN code, password |
| Payment method | Card payment / QR code payment |
| Communication interface | Ethernet, 4G |
| Protocol | OCPP1.6J / OCPP2.0 |
| Warranty | 2 years |
| Customize | Brand-your brand logo |
| Language | English or customize other language |
| Dimension | — |
