1. Output power: 14KW, 0-64A, AC220V；
2. Input voltage: single-phase input 220V AC power;
3. Leakage current ≤ 30MA, during operation ≤ 0.1S;
4. Installation method: floor standing;
5. Protection level: IP55;
6. Communication: 2G/3G/4G, Ethernet;
7. Equipped with card reader, 5.6-inch without touch screen, self metering, board lightning protection (8000V);
8. Charging connection method: GB/T 18487.1-2017 Charging method C
Technical Specifications Overview
| Model | Output Power | Voltage & Current | Phase | Connector |
|---|---|---|---|---|
| 7kW | 230V, 32A | Single-phase | 1P | Type 2 |
| 14kW | 400V, 20A | Three-phase | 3P | Type 2 |
| 22kW | 400V, 32A | Three-phase | 3P | Type 2 |
Additional features like Wi-Fi/4G modules, smart billing, and multilingual UI can be added per request.
OEM & Customization Service
Cansin provides full OEM services:
-
Logo printing
-
Customized housing color
-
APP integration
-
Charging platform access via OCPP
-
Firmware localization and diagnostics
